Ingiant pneumatic rotary joint 1 channels for engineering machines
Product maintenance
- The rotating joint drum and the inside of the pipe shall be kept clean. Special attention shall be paid to new equipment. If necessary, a filter shall be added to avoid abnormal wear of rotating joints caused by foreign matters.
- As the machine will not be used for a long time, it will cause scaling and rusting inside the rotary joint. Please note that if the machine is reused, it will get stuck or drip.
- If there is an oil filling device, please fill oil regularly to ensure the reliability of the rotating joint bearing.
- The rotating joint of fluid medium shall be gradually heated to avoid sudden temperature change.
- Check the wear condition and thickness change of the sealing surface (generally, the normal wear is 5–10mm); Observe the friction track of the sealing surface to see if there are three intermittent points, scratches and other problems. If there is any problem, replace it immediately.
- The rotary joint shall be handled with care and shall not be impacted to avoid loss of joint components.
- It is forbidden for foreign matters to enter the inside of the rotary joint.
- Do not idle the rotary joint for a long time.
|
LHS048-1Q |
|
|
Technical parameters |
|
|
Passages |
According to requirement of customers |
|
Thread |
M5 |
|
Flow hole size |
Φ4 |
|
Working medium |
compressed air |
|
Working pressure |
1.1 Mpa |
|
Working speed |
≤200rpm |
|
Working temperature |
“-30℃~+80℃” |
Standard product outline drawing:
Our advantage:
- Product advantage: Ingiant rotary joint can perform rotation of 360 degrees. The medium includes inert gas such as compressed air, steam, vacuum, nitrogen, hydrogen, etc. It can integrate slip ring to transport various control signals. The sealing surface and sealing ring are made of special materials, with the advantages of wear resistance, long life, corrosion resistance, and no leakage. Customers can install LPP rotary unions independently according to the application environment. ;Customized rotary joint parameters and integrated slip ring can be customized according to customer requirements;The joint and pipe diameter can be customized according to customer requirements;
- Company advantage: Owns complete mechanical processing equipments including a CNC processing center, with strict inspection and testing standards which can meet national military GJB standard and quality management system, moreover, Ingiant owns 27 kinds of technical patents of slip rings and rotary joints(include 26 untility model patents, 1 invention patent), so we have a big strength on R&D and production process. More than 60 workers with several years experience in workshop production, skilled in operation and production, can better guarantee product quality.
- Excellent after-sales and technical support service:Customized, accurate and timely service for customers in terms of pre-sales, production, after-sales and product warrenty, our goods are guaranteed for 12 months from date of sale,under guaranteed time non human damage, free maintenance or replacement for quality problems arising from the products.
