DHK050-46 Standard 50mm through hole Gigabit Ethernet slip ring with 1 channel Gigabit Ethernet signal

Gigabit Ethernet Slip Ring DHK050-46 Series

DHK050-46 series with through hole 50mm, OD 120mm, suitable for rotating application which requires a through hole ≤50mm, standard model supports 1-18 power rings(0-20A/ring) or 1-72 signal rings(0~5A/ring), combine with 1~3 channels 1000M Ethernet signal.


  • Multi-point brush contact material ensure long life
  • Stable transmit 1 channels Gigabit Ethernet signal
  • Integrated structure design for easy installation
  • Standard model and customization are available
  • IP 51 (IP54-IP68 can be customized)
  • RJ45 male connectors、 RJ45 female optional
  • Ethernet cable connection
  • With advantages of reliable transmitting, no packet loss, no string code, low return loss, low insertion loss, etc.
  • Free maintenance

Typical applications: Automatic machines, cable reels, robots, rotary sensors, emergency lighting equipment, exhibition/display equipment, packaging machinery, rotary tables, medical, pharmaceutical equipment, processing machinery, capping machines, labeling machines, filling machines, machine tools
