Ingiant solid shaft flange slip rings used well in drone and RC flight model
Flange slip rings are very compact solutions with fiber brush technology and high performance. The cable connection on the rotor and stator side is made via flat connectors directly on the housing. They are not only small and compact, but also particularly easy to install.
Flange slip rings have proven themselves particularly well in drone and RC flight model construction. They are suitable for high speeds on rotors and propellers as well as for precise control of camera gimbals. If a Faston slip ring needs to be replaced, it can be done in a few easy steps.
We offer Flange slip rings with up to six rings for transmitting power current and 2 rings for transmitting signals. Up to 25 amps can be transmitted per ring. The maximum working voltage is 380 volts. Overall, each slip ring can withstand voltages up to 500 volts, but can also withstand voltage spikes up to 1000 volts.
Flange slip rings allow continuous or alternating rotation of up to 300 revolutions per minute. The standard contact material used in Faston slip rings is silver.
|
DHS064-27-2S |
|||
|
The main parameters |
|||
| Number of circuits | 27 | Working temperature | “-40℃~+65℃” |
| Rated current | can be customized | Working humidity | ＜70% |
| Rated voltage | 0~240 VAC/VDC | Protection level | IP54 |
| Insulation resistance | ≥1000MΩ @500VDC | Housing material | Aluminum Alloy |
| Insulation strength | 1500 VAC@50Hz,60s,2mA | Electrical contact material | Precious metal |
| Dynamic resistance variation | ＜10MΩ | Lead wire specification | Colored Teflon insulated & tinned stranded flexible wire |
| Rotating speed | 0~600rpm | Lead wire length | 500mm + 20mm |
All of the above can be customized except (Insulation resistance. Insulation strength. Dynamic resistance variation), if there is no suitable standard products, can be customized according to your requirements.
Standard Product Outline Drawing:
Our advantage:
- Product advantage: Flange slip rings are very compact solutions with fiber brush technology and high performance. The cable connection on the rotor and stator side is made via flat connectors directly on the housing. They are not only small and compact, but also particularly easy to install.
- Company advantage: Ingiant covers an area of more than 8000 square meters of scientific research & production space and with a professional design & manufacturing team of more than 150 staffs; The company owns complete mechanical processing equipment including a CNC processing center, with strict inspection and testing standards which can meet national military GJB standard and quality management system, own 27 kinds of technical patents of slip rings and rotary joints(include 26 utility model patents, 1 invention patent).
- Customised advantage: Customized advantage: We can supply you with quantities from 1. Special shapes or special types are possible on request. Give us a call. We will discuss your challenges until we have found your optimal slip ring. Trust our competence and experience. Our encapsulated miniature slip rings are used in tens of thousands of applications worldwide.
