DHK090-114 Standard 90mm through hole slip ring transmits 119 channels of power and signal
Through hole slip ring – DHK090-114 series
Support customization, product inner diameter 3-500mm, 2-1000A
DHK090-114 series through-hole conductive slip ring, inner hole 90mm, suitable for rotating electromechanical systems with diameter less than 90mm, standard power ring 20A/ring, maximum 48 rings, signal ring 5A/ring, maximum 96 rings, used for 360 degrees Transmit power or signals in rotating systems.
Features
- Multi-contact brush contact design, long service life
- Integrated structural design, easy to install
- 114 channels power and signals
- IP54 protection level, can be customized
- Adopt a more reliable all-metal shell protective structure
- Maintenance-free use
- Able to integrate power, signal and data in a rotating transmission system without interference
Typical applications: medical equipment, CNC turntables, CNC machining centers, automation equipment, robotic arms, wire reels, cable reels, packaging machinery, filling equipment, wind turbines, automated robots, fully automatic inspection equipment, VR, etc.
|
DHK090-114 |
|||
|
The main parameters |
|||
| Number of circuits | 114 | Working temperature | “-40℃~+65℃” |
| Rated current | 2A.5A.10A.15A.20A | Working humidity | ＜70% |
| Rated voltage | 0~240 VAC/VDC | Protection level | IP54 |
| Insulation resistance | ≥1000MΩ @500VDC | Housing material | Aluminum Alloy |
| Insulation strength | 1500 VAC@50Hz,60s,2mA | Electrical contact material | Precious metal |
| Dynamic resistance variation | ＜10MΩ | Lead wire specification | Colored Teflon insulated & tinned stranded flexible wire |
| Rotating speed | 0~600rpm | Lead wire length | 500mm + 20mm |
Standard product outline drawing:
